Home » Products » UHMW (Ultra High Molecular Weight Polyethylene) » Ultra High Molecular Weight Polyethylene (UHMW)

Ultra High Molecular Weight Polyethylene (UHMW)

UHMW, also known as UHMW-PE (Ultra High Molecular Weight Polyethylene), is a semi-crystalline thermoplastic material, with a continuous use temperature range of up to 180° F (82° C).

More about Ultra High Molecular Weight Polyethylene (UHMW) »

Benefits of Ultra High Molecular Weight Polyethylene (UHMW)

<p>Superior abrasion resistance</p>

Superior abrasion resistance

<p>Low coefficient of friction</p>

Low coefficient of friction

<p>Good corrosion resistance</p>

Good corrosion resistance

<p>Excellent impact strength</p>

Excellent impact strength

Product Options

Colors

Sheet and Rod: Natural, Black, Blue, Green | Tube: Natural, Black, Blue, Green

Grades

Bearing Grade
Ceramic Filled
FDA
Virgin
Glass Filled
Reprocessed
Oil Filled
Static Dissipative
UV Resistant
Flame Retardant
High Temperature
Metal Detectable

Sizes

Shape

Sizes

sheet

Dimensions: 12″ x 12″ to 60″ x 120″
Thickness: 0.060″ – 6″

rod

Diameter: 0.25″ – 10″
Length: 1′ – 10′

tube

Outside Diameter: 0.875″ – 9.5″
Length: 5′ – 10′

Technical Resources

Suppliers / Brands

Mitsubishi Chemical Advanced Materials

Tivar®

Polymer Industries

Rochling

Common Applications

Physical Properties

	Units	ASTM Test	Ultra High Molecular Weight Polyethylene
Tensile strength @ break @ 73°F	psi	D638	3,550 – 5,800
Flexural modulus @ 73°F	psi	D790	98,300 – 222,000
Izod impact (notched)	ft-lbs/in of notch	D256	1.0 – 16
Water absorption @ 73°F – 24 hours	%	D570	<0.01
Coefficient of linear thermal expansion (CLTE)	(in/in F)	D696	6.8E-5 to 7.8E-5
Coefficient of friction		D1894	0.08 – 0.2
Deflection Temperature Under Load @ 264 psi	°F	D648	154 – 173

* Technical Data is provided courtesy of UL Prospector (www.ulprospector.com) and IAPD (www.IAPD.org).

Data is to be considered representative and is provided for guidance only. All product performance must be verified by the user under actual application conditions.

About Ultra High Molecular Weight Polyethylene (UHMW)

UHMW, also known as UHMW-PE (Ultra High Molecular Weight Polyethylene), is a semi-crystalline thermoplastic material, with a continuous use temperature range of up to 180° F (82° C). It is categorized as an engineering material, and offers a unique combination of wear and corrosion resistance, a low-friction surface, and high impact strength.

UHMW exhibits very low moisture absorption, and retains key physical properties at temperatures as low as minus-22° F (minus-30° C). It offers very good electrical insulating properties, moderate mechanical strength and stiffness, and excellent machinability. It is an excellent general-purpose material which offers performance properties that make it effective in a tremendous range of applications, particularly food handling solutions, conveyance mechanisms and material handling, and packaging solutions where wear resistance and durability are crucial. Plus, UHMW meets a wide range of regulatory compliance standards, including 3-A Dairy, ASTM/Mil-Spec, FDA, UL-94 Flame Class, and USDA.

Polymershapes proudly offers UHMW from industry-leading manufacturers, including Mitsubishi Chemical Advanced Materials (formerly Quadrant EPP), makers of Tivar®. We can meet your UHMW needs in a variety of shapes and sizes, including sheet, rod, and tube. We can also provide you with various grades of this versatile material, including bearing grade, ceramic filled, FDA, virgin, glass filled, reprocessed, oil filled, static dissipative, UV resistant, flame retardant, high temperature, and metal detectable. Available colors include natural, black, blue and green.

Did you know that Polymershapes can help you meet all your requirements for plastics and associated products? We carry a vast array of material solutions, and we will provide you a wide range of industry-leading value-added capabilities. Our local facilities, film conversion centers and fabrication centers are staffed by experienced teams eager deliver best-in-class convenience and customer service.

Polymershapes looks forward to helping you meet your needs for UHMW, and more! — contact your local Polymershapes facility today for more information!
